Signage Solutions Q-Line Display
43BDL3511QInform and enthrall with a Philips Q-Line Professional Ultra HD Display. This reliable solution can be up and running as quickly as you need.
Operate, monitor and maintain with CMND & Control
Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.
FailOver ensures content is always playing
From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.
Schedule what you want, when you want with SmartPlayer
Turn your USB into a true cost effective digital signage device. Simply save your content (video, audio, pictures) on your USB and plug into your display.Create your playlist and schedule your content via the on screen menu, and enjoy your own created playlists anytime, anywhere.
Integrated media player. Easily schedule USB content
Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done.
Technical Specifications
-
Picture/Display
- Diagonal screen size (metric)
-
108 cm
- Diagonal screen size (inch)
-
42.5 inch
- Panel resolution
-
3840 x 2160
- Optimum resolution
-
3840 x 2160 @ 60 Hz
- Brightness
-
400 cd/m²
- Dynamic contrast ratio
-
500,000:1
- Response time (typical)
-
8 ms
- Aspect ratio
-
16:9
- Viewing angle (horizontal)
-
178 degree
- Viewing angle (vertical)
-
178 degree
- Pixel pitch
-
0.2451 x 0.2451 mm
- Display colors
-
1.07 Billion
- Panel technology
-
IPS
- Contrast ratio (typical)
-
1200:1
- Clinical image
-
D-Image preset (dicom part 14 compatible)
- Haze
-
1%
-
Supported Display Resolution
- Computer formats
-
-
640 x 480, 60, 67, 72, 75Hz
-
720 x 400, 70Hz
-
800 x 600, 56, 60, 72, 75Hz
-
832 x 624, 75Hz
-
1024 x 768, 60, 70, 75Hz
-
1152 x 864, 75Hz
-
1152 x 870, 75Hz
-
1280 x 720, 60Hz
-
1280 x 800, 60Hz
-
1280 x 1024, 60Hz
-
1440 x 900, 60Hz
-
1600 x 1200, 60Hz
-
1680 x 1050, 60Hz
-
1920 x 1080, 60Hz
-
- Video formats
-
-
480i, 60Hz
-
480p, 60Hz
-
576p, 50Hz
-
576i, 50Hz
-
720p, 60Hz
-
1080i, 50, 60Hz
-
1080p, 50, 60Hz
-
3840 x 2160, 30Hz
-
3840 x 2160, 60Hz
-
-
Connectivity
- Video input
-
-
DVI-I (x 1)
-
HDMI 2.0 (x2)
-
USB 2.0 (x2)
-
- Audio input
-
3.5 mm jack
- Audio output
-
3.5mm jack
- External control
-
-
IR (in/out) 3.5 mm jack
-
RJ45
-
RS232C (in/out) 2.5 mm jack
-
-
Convenience
- Placement
-
-
Landscape (18/7)
-
Portrait (18/7)
-
- Tiled Matrix
-
Up to 10 x 15
- Signal loop through
-
-
RS232
-
IR Loopthrough
-
- Energy saving functions
-
Smart Power
- Network controllable
-
-
RS232
-
RJ45
-
- Keyboard control
-
-
Hidden
-
Lockable
-
- Remote control signal
-
Lockable
- Start-up
-
-
Switch on delay
-
Switch on status
-
Boot on source
-
- Start-up window
-
enable / disable Philips logo
-
Operating conditions
- Temperature range (operation)
-
0 ~ 40 °C
- Temperature range (storage)
-
-20 ~ 60 °C
- Altitude
-
0 ~ 3000 m
- MTBF
-
50,000 hour(s)
- Humidity range (operation)[RH]
-
20 ~ 80% RH (No condensation)
- Humidity range (storage) [RH]
-
5 ~ 95% RH (No condensation)
-
Power
- Consumption (Typical)
-
105 W
- Consumption (Max)
-
155 W
- Standby power consumption
-
<0.5 W
- Mains power
-
100 - 240V~, 50/60Hz
- Power Saving Features
-
Smart Power
- Energy Label Class
-
G
-
Sound
- Built-in speakers
-
2 x 10W RMS
-
Accessories
- Stand
-
BM05922(optional)
- Included Accessories
-
-
IR sensor cable (1.8 m) (x1)
-
Philips logo (x1)
-
AC power cord
-
AC Switch Cover
-
Quick start guide (x1)
-
Remote control & AAA batteries
-
RS232 daisy chain cable (x1)
-
USB Cover and screw x1
-
Wire Clamper (x3)
-
-
Miscellaneous
- On-Screen Display Languages
-
-
Arabic
-
English
-
French
-
German
-
Italian
-
Japanese
-
Polish
-
Russian
-
Spanish
-
Simplified Chinese
-
Turkish
-
Traditional Chinese
-
- Regulatory approvals
-
-
CE
-
FCC, Class A
-
CB
-
BSMI
-
VCCI
-
CU
-
ETL
-
EMF
-
PSB
-
- Warranty
-
3 year warranty
-
Multimedia Applications
- USB Playback Video
-
-
H.264
-
JPEG
-
MPEG
-
WMV3
-
- USB Playback Picture
-
-
BMP
-
JPEG
-
PNG
-
- USB Playback Audio
-
-
AAC
-
WMA
-
MPEG
-
HEAAC
-
-
Dimensions
- Set Width
-
973.0 mm
- Set Height
-
561.2 mm
- Set Depth
-
63.5 mm
- Set Width (inch)
-
38.31 inch
- Set Height (inch)
-
22.09 inch
- Set Depth (inch)
-
2.50 inch
- Bezel width
-
13.9 mm (Even bezel)
- Wall Mount
-
200mm x 200mm , M6
- Product weight
-
10.7 kg
- Product weight (lb)
-
23.59 lb
