Philips 32BDL3550Q Q-Line 32" Signage Solutions Display

$818.00

SKU: 32BDL3550Q

Philips 32BDL3550Q Signage Solutions Q-Line Display

Intensify your signage experience

Inform and enthrall with a Philips Q-Line Professional Full HD Display. This reliable solution can be up and running as quickly as you need-with no additional hardware.

Operate, monitor and maintain with CMND & Control

Run your display network over a local (LAN) connection. CMND & Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you're in charge of one screen or 100.

FailOver ensures content is always playing

From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs ensuring content keeps playing even if the primary source goes down. Simply set a list of alternate inputs to be sure your business is always on.

CMND & Create. Develop and launch your own content

Take control of your content with CMND & Create. A drag-and-drop interface makes it simple to publish your own content-whether it's a daily specials board or branded corporate information. Preloaded templates and integrated widgets ensure your stills, text, and video will be up and running in no time.

Integrated media player. Easily schedule USB content

Easily schedule content to play from USB. Your Philips Professional Display will wake from standby to play the content you want, and then return to standby once playback is done.

Android SoC processor. Native and web apps

Control your display via an Internet connection. Android-powered Philips Professional Displays are optimized for native Android apps, and you can install web apps directly to the display too. A new Android 8 ensures the software is kept secure and remain to the latest specification for longer.

Connect and control your content over the internet

Connect and control your content over the internet with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Streaming content can also be shown in a PIP (picture-in-picture) window. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlist

Connect and control your content via the cloud

Connect and control your content via the cloud with the integrated HTML5 browser. Using the Chromium based browser, design your content online and connect a single display, or your complete network. Show content in both landscape and portrait mode, with fullHD resolution. Simply connect the display to the internet using WiFi or with an RJ45 cable, and enjoy your own created playlists.

Technical Specifications

Picture/Display
Diagonal screen size (metric)

80 cm

Diagonal screen size (inch)

31.5 inch

Panel resolution

1920x1080p

Optimum resolution

1920 x 1080 @ 60 Hz

Brightness

350 cd/m²

Contrast ratio (typical)

4000:1

Dynamic contrast ratio

500,000:1

Response time (typical)

8 ms

Aspect ratio

16:9

Viewing angle (horizontal)

178 degree

Viewing angle (vertical)

178 degree

Pixel pitch

0.36375 x 0.36375 mm

Display colors

16.7 Million

Panel technology

VA

Picture enhancement
- 3/2 - 2/2 motion pull down
- 3D Combfilter
- 3D MA deinterlacing
- Dynamic contrast enhancement
- Motion compens. deinterlacing
- Progressive scan
Clinical image

D-Image preset (dicom part 14 compatible)

Operating system

Android 8.0
Supported Display Resolution
Computer formats
- 1920 x 1080, 60Hz
- 1680 x 1050, 60Hz
- 1600 x 1200, 60Hz
- 1440 x 900, 60Hz
- 1280 x 1024, 60Hz
- 1280 x 800, 60Hz
- 1280 x 720, 60Hz
- 1152 x 870, 75Hz
- 1024 x 768, 60, 70, 75Hz
- 800 x 600, 56, 60, 72, 75Hz
- 720 x 400, 70Hz
- 640 x 480, 60, 67, 72, 75Hz
- 1152 x 864, 75Hz
- 832 x 624, 75Hz
Video formats
- 576p, 50Hz
- 576i, 50Hz
- 480p, 60Hz
- 480i, 60Hz
- 1080p, 50, 60Hz
- 1080i, 50, 60Hz
- 3840 x 2160, 30Hz
- 3840 x 2160, 60Hz
- 720p, 50,60 Hz
Connectivity
Video input
- DVI-I (x 1)
- HDMI 2.0 (x2)
- USB 2.0 (x2)
Audio input

3.5 mm jack

Audio output

3.5mm jack

External control
- RJ45
- RS232C (in/out) 2.5 mm jack
- IR (in/out) 3.5 mm jack
Convenience
Energy saving functions

Smart Power

Tiled Matrix

Up to 15 x 15

Start-up
- Switch on delay
- Switch on status
- Boot on source
Start-up window

enable / disable Philips logo

Keyboard control
- Lockable
- Hidden
Network controllable
- RS232
- RJ45
Signal loop through
- RS232
- IR Loopthrough
Placement
- Landscape (18/7)
- Portrait (18/7)
Remote control signal

Lockable
Dimensions

Bezel width

11.9 (TLR) / 17.2 (B) mm

Set Width

726.5 mm

Set Height

425.4 mm

Set Depth

69.1(D@Handle) / 65.1(D@Wall mount) mm

Set Width (inch)

28.6 inch

Set Height (inch)

16.75 inch

Set Depth (inch)

2.72 (D@Handle) / 2.56 (D@Wall mount)f inch

VESA Mount

100mm x100mm, 200mm x 200mm ,M4

Product weight

5.31 kg

Product weight (lb)

11.71 lb
Operating conditions

Temperature range (operation)

0 ~ 40 °C

Temperature range (storage)

-20 ~ 60 °C

MTBF

50,000 hour(s)

Altitude

0 ~ 3000 m

Humidity range (operation)[RH]

20 ~ 80% RH (No condensation)

Humidity range (storage) [RH]

5 ~ 95% RH (No condensation)
Power

Mains power

100 - 240V~, 50-60Hz, 1.5A

Standby power consumption

<0.5 W

Consumption (Max)

80 W

Consumption (Typical)

50 W

Power Saving Features

Smart Power

Energy Label Class

G
Sound

Built-in speakers

2 x 10W RMS
Multimedia Applications
USB Playback Video
- MPEG
- H.264
- H.263
- H.265
USB Playback Picture
- BMP
- JPEG
- PNG
USB Playback Audio
- AAC
- HEAAC
- MPEG
Accessories
Included accessories
- AC Power Cord
- RS232 cable
- Remote Control
- Batteries for remote control
- Quick start guide
Included Accessories
- IR sensor cable (1.8 m) (x1)
- RS232 daisy-chain cable
- Philips logo (x1)
- USB Cover and screw (x2)
Stand

BM02541/BM05911(optional)
Miscellaneous
Warranty

3 year warranty

On-Screen Display Languages
- English
- French
- German
- Italian
- Polish
- Turkish
- Russian
- Simplified Chinese
- Spanish
- Traditional Chinese
- Arabic
- Japanese
Regulatory approvals
- CB
- CE
- BSMI
- CU
- EPA
- ETL
- FCC, Class A
- J-Moss
- VCCI
Internal Player
CPU
- Dual core cortex A53 1.1G Hz
- Dual core cortex A73 1.15G Hz
GPU

ARM Mali G51

Memory
- 2GB DDR3
- 8GB

What's in the box?

Other items in the box

AC Power Cord
RS232 cable
Remote Control
Batteries for remote control
Quick start guide
