Low Profile "Slim" Design
A lot of the other brackets which can tilt forwards and also pivot/swivel left and right are quite bulky and can't fold up very compactly, making it hard to position your TV close to the wall. This bracket doesn't have that problem: it can fold back to within 46mm from the wall. But please note that many manufacturers recommend that LCDs and plasmas are not to be mounted within a certain distance from the wall, due to heat and ventilation concerns.

Features:
- Low profile "slim" design: 46mm from wall
- Suits screen size 23" to 55"
- Max extension: 542mm
- Pivot/Swivel: up to 90 degrees each way (left/right)
- 3 points of horizontal adjustment
- Tilt: -2 ~ 12 degrees
- Also includes a free reusable bubble level
- Ideal for single stud walls

Horizontal Swivel/Pivot (Left/Right)
This bracket allows you to turn your TV up to 90 degrees to the left or right. Please note that larger TVs may be limited to an angle smaller than 90 degrees.

Free Bubble Level
This bracket includes a reusable bubble level / spirit level to assist with accurate installation of the bracket.

Will This Bracket Fit My TV / Monitor?


This bracket will fit your TV screen (and not be visible from front on) if your TV is:
- At least 425mm wide.
- At least 425mm tall.
The four threaded mounting holes on the back of your TV need to be:
- No more than 400mm apart side to side.
- No more than 400mm apart top to bottom.
Maximum TV weight capacity is 30kg.

Full VESA patterns supported: 100x100, 200x100, 200x200, 300x300, 400x200, 400x400

Screws/Bolts
This bracket includes a variety of screws/bolts which are suitable for most installations. Unfortunately, due to the enormous range of TV brands and models available, we're unable to guarantee that the included fixings will suit every installation.

As with all wall brackets, if mounting on plasterboard walls it is essential that this bracket is fixed to timber studs.
